Threat actor DEV-0322 exploiting ZOHO ManageEngine ADSelfService Plus

Microsoft has detected exploits being used to compromise systems running the ZOHO ManageEngine ADSelfService Plus software versions vulnerable to CVE-2021-40539 in a targeted campaign. Microsoft Threat Intelligence Center (MSTIC) attributes this campaign with high confidence to DEV-0322, a group operating out of China, based on observed infrastructure, victimology, tactics, and procedures.

MSTIC previously highlighted DEV-0322 activity related to attacks targeting the SolarWinds Serv-U software with 0-day exploit. As with any observed nation-state actor activity, Microsoft notifies customers that have been targeted or compromised, providing them with the information they need to help secure their accounts.

Our colleagues at Palo Alto Unit 42 have also highlighted this activity in their recent blog. We thank Unit 42 for their collaboration as industry partners and ongoing efforts to protect customers. We would also like to thank our partners in Black Lotus Labs at Lumen Technologies for their contributions to our efforts to track and mitigate this threat.

This blog shares what Microsoft has observed in the latest DEV-0322 campaign and inform our customers of protections in place through our security products. We have not observed any exploit of Microsoft products in this activity.

MSTIC uses DEV-#### designations as a temporary name given to an unknown, emerging, or developing cluster of threat activity, allowing MSTIC to track it as a unique set of information until we can reach high confidence about the origin or identity of the actor behind the activity. Once it meets defined criteria, a DEV group is converted to a named actor.

Activity description

MSTIC first observed the latest DEV-0322 campaign on September 22, 2021, with activity against targets that appear to be in the Defense Industrial Base, higher education, consulting services, and information technology sectors. Following initial exploitation of CVE-2021-40539 on a targeted system, DEV-0322 performed several activities including credential dumping, installing custom binaries, and dropping malware to maintain persistence and move laterally within the network.

Credential dumping

In this campaign, DEV-0322 was observed performing credential dumping using the following commands:

Screenshot of commands use for credential dumping

DEV-0322 also occasionally deployed a tool to specifically read security event logs and look for Event ID 4624 events. Next, their tool would collect domains, usernames, and IP addresses and write them to the file elrs.txt. They typically called this tool elrs.exe, and below is an example of how they would call it:

Screenshot of command for calling elrs.exe

After gaining credentials, DEV-0322 was observed moving laterally to other systems on the network and dropping a custom IIS module with the following command:

Screenshot of command for moving laterally and dropping a custom IIS module

Installing custom IIS module

The gac.exe binary installs ScriptModule.dll into the Global Assembly Cache before using AppCmd.exe to install it as an IIS module. AppCmd.exe is a command line tool included in IIS 7+ installations used for server management. This module hooks into the BeginRequest IIS http event and looks for custom commands and arguments being passed via the Cookies field of the HTTP header.

Screenshot of request headers using encoded request from the controller to the victim machine

Figure 1: Encoded request from the controller to the victim machine

The custom IIS module supports execution for cmd.exe and PowerShell commands. It also provides DEV-0322 with the ability to direct download and upload of files to and from a compromised IIS web server. The module also observes incoming authentication credentials and captures them; it then encodes these and writes them to the following path:

C:\ProgramData\Microsoft\Crypto\RSA\key.dat

If this module receives the command “ccc,” it drops a file c:\windows\temp\ccc.exe. The file ccc.exe is a .NET program that launches cmd.exe with an argument and sends any output back to the controller.

Screenshot of Base64-encoded ccc.exe

Figure 2: The Base64-encoded ccc.exe contained inside the IIS module backdoor

Below is an example command from w3wp.exe process after ccc.exe is dropped:

"c:\windows\temp\ccc.exe" dir

Deploying Zebracon malware

In addition to a custom IIS module, DEV-0322 also deployed a Trojan that we are calling Trojan:Win64/Zebracon. This Trojan uses hardcoded credentials to make connections to suspected DEV-0322-compromised Zimbra email servers.

Subsequent commands are made to <ZimbraServer>/service/soap using an obtained authorization token (ZM_AUTH_TOKEN) to perform email operations on the threat actor-controlled mailbox, such as the following:

  • Search email (e.g., <query>(in:\”inbox\” or in:\”junk\”) is:unread</query>)
  • Read email
  • Send email (e.g., Subject: [AutoReply] I’ve received your mail, I will check it soon!)

These operations are used by the Zebracon malware to receive commands from the DEV-0322-controlled mailbox.

Files related to the Zebracon Trojan have the following metadata:

  • Company name:
    • Synacor. Inc.
  • File description:
    • Zimbra Soap Suites
    • Zimbra Soap Tools
  • Internal name:
    • newZimbr.dll
    • zimbra-controller-dll.dll
  • Original filename:
    • newZimbr.dll
    • ZIMBRA-SOAP.DLL

Microsoft will continue to monitor DEV-0322 activity and implement protections for our customers. The current detections, advanced detections, and IOCs in place across our security products are detailed below.

Detections

Microsoft 365 Defender detections

Antivirus

Microsoft Defender Antivirus detects threat components as the following malware:

  • Trojan:MSIL/Gacker.A!dha
  • Backdoor:MSIL/Kokishell.A!dha
  • Trojan:Win64/Zebracon.A!dha

Endpoint detection and response (EDR)

Alerts with the following titles in the security center can indicate threat activity on your network:

  • DEV-0322 Actor activity detected​
  • Malware from possible exploitation of CVE-2021-40539

The following alerts may also indicate activity associated with this threat. These alerts can be triggered by unrelated threat activity, but they are listed here for reference:

  • ‘Zebracon’ high-severity malware was detected
  • Anomaly detected in ASEP registry

Microsoft 365 Defender correlates any related alerts into incidents to help customers determine with confidence if observed alerts are related to this activity. Customers using the Microsoft 365 Defender portal can view, investigate, and respond to incidents that include any detections related to this DEV-0322 activity.

The threat and vulnerability management module in Microsoft Defender for Endpoint (included in Microsoft 365 Defender) provides insights related to CVE-2021-40539. Customers can find affected devices in their environment in the Microsoft 365 Defender portal and initiate the appropriate version update of the ManageEngine software. Customers can also use the hunting query included below to identify devices that might be vulnerable to CVE-2021-40539.

Microsoft Sentinel detections

The indicators of compromise (IoCs) included in this blog post are also available to Microsoft Sentinel customers through the Microsoft Emerging Threat Feed located in the Microsoft Sentinel Threat Intelligence blade. These can be used by customers for detection purposes alongside the hunting queries detailed below.

Advanced hunting queries

Microsoft Sentinel hunting queries

Name:  DEV-0322 Command Line Activity November 2021
Description: This hunting query looks for process command line activity related to observed DEV-0322 activity as detailed in this blog post. It locates command lines that are used as part of the threat actor’s post-exploitation activity. The query uses additional data from Microsoft Defender for Endpoint to generate a risk score associated with each result. Hosts with higher risk events should be investigated first.

https://github.com/azure/azure-sentinel/blob/master/Hunting%20Queries/MultipleDataSources/Dev-0322CommandLineActivityNovember2021.yaml

Name:  DEV-0322 File Drop Activity November 2021
Description: This hunting query looks for file creation events related to observed DEV-0322 activity as detailed in this blog. The files this query hunts for are dropped as part of the threat actor’s post-exploitation activity. The query uses other additional data from Microsoft Defender for Endpoint to generate a risk score associated with each result. Hosts with higher risk events should be investigated first.

https://github.com/azure/azure-sentinel/blob/master/Hunting%20Queries/MultipleDataSources/Dev-0322FileDropActivityNovember2021.yaml

In addition to these queries, there are equivalent queries that use the Microsoft Sentinel Information Model (MSIM) to look for the same activity. If you are using MSIM you can find these queries here:

Microsoft 365 Defender hunting queries

Name: Surface devices with the CVE-2021-40539 vulnerability
Description: Use this query to look for devices in your organization that are possibly vulnerable to CVE-2021-40539. Run query.

DeviceTvmSoftwareVulnerabilities
| where CveId == "CVE-2021-40539"
| project DeviceId, DeviceName, CveId, OSPlatform, SoftwareName, SoftwareVersion

Name: Hunt for suspicious dropped files post-exploitation
Description: Look for suspicious files dropped the the threat actor’s post-exploitation activity. Run query.

// Look for the specific files dropped by threat actor
let files = dynamic(["C:\\ProgramData\\Microsoft\\Crypto\\RSA\\key.dat ", "c:\\windows\\temp\\ccc.exe"]);
DeviceFileEvents
| where FileName endswith "elrs.exe" or FolderPath has_any (files)
// Increase the risk score of command accessing file also seen
| join kind=leftouter (DeviceProcessEvents
| where ProcessCommandLine contains "cmd /c elrs.exe") on DeviceId
| project-reorder Timestamp, DeviceName, FileName, FolderPath, ProcessCommandLine, InitiatingProcessAccountName

Name: Hunt for command lines observed used by the DEV-0322 actor
Description: Look for suspicious command lines that are used as part of the threat actor’s post-exploitation activity. Run query.

// Look for command lines observed used by the threat actor
let cmd_lines = dynamic(['cmd.exe /c "wmic /node:redacted process call create "ntdsutil snapshot \\"activate instance ntds\\" create quit quit > c:\\windows\\temp\\nt.dat";', 'regsvr32 /s c:\\windows\\temp\\user64.dll', 'process call  create "cmd /c c:\\windows\\temp\\gac.exe -i c:\\windows\temp\\ScriptModule.dll >c:\\windows\\temp\\tmp.dat"']);
DeviceProcessEvents
// Look for static cmd lines and dynamic one using regex
| where ProcessCommandLine has_any (cmd_lines) or ProcessCommandLine matches regex "save HKLM\\SYSTEM [^ ]*_System.HIV" or InitiatingProcessCommandLine has_any (cmd_lines) or InitiatingProcessCommandLine  matches regex "save HKLM\\SYSTEM [^ ]*_System.HIV"
| summarize count(), FirstSeen=min(Timestamp), LastSeen = max(Timestamp) by DeviceId, DeviceName, ProcessCommandLine, AccountName, FileName, InitiatingProcessCommandLine, InitiatingProcessFileName, InitiatingProcessAccountName, InitiatingProcessAccountSid
// Base risk score on number of command lines seen for each host
| extend RiskScore = count_
| project-reorder  FirstSeen, LastSeen, RiskScore, DeviceName, DeviceId, ProcessCommandLine, AccountName
| extend timestamp = FirstSeen, AccountCustomEntity = AccountName, HostCustomEntity = DeviceName

Indicators of compromise (IOCs)

Type Indicator
SHA-256 bb4765855d2c18c4858dac6af207a4b33e70c090857ba21527dc2b22e19d90b5
SHA-256 e5edd4f773f969d81a09b101c79efe0af57d72f19d5fe71357de10aacdc5473e
SHA-256 79e3f4ef28ab6f118c839d01a404cccae56f4067f3f2d2add3603be5c717932b
SHA-256 a2da9eeb47a0eef4a93873bcc595f8a133a927080a2cd0d3cb4b4f5101a5c5c2
SHA-256 d1d43afd8cab512c740425967efc9ed815a65a8dad647a49f9008732ffe2bb16
SHA-256 3c90df0e02cc9b1cf1a86f9d7e6f777366c5748bd3cf4070b49460b48b4d4090
SHA-256 ae93e2f0b3d0864e4dd8490ff94abeb7279880850b22e8685cd90d21bfe6b1d6
SHA-256 b4162f039172dcb85ca4b85c99dd77beb70743ffd2e6f9e0ba78531945577665
SHA-256 b0a3ee3e457e4b00edee5746e4b59ef7fdf9b4f9ae2e61fc38b068292915d710
SHA-256 bec067a0601a978229d291c82c35a41cd48c6fca1a3c650056521b01d15a72da
SHA-256 1e031d0491cff504e97a5de5308f96dc540d55a34beb5b3106e5e878baf79d59
SHA-256 f757d5698fe6a16ec25a68671460bd10c6d72f972ca3a2c2bf2c1804c4d1e20e
SHA-256 322368e7a591af9d495406c4d9b2461cd845d0323fd2be297ec06ed082ee7428
SHA-256 5fcc9f3b514b853e8e9077ed4940538aba7b3044edbba28ca92ed37199292058
SHA-256 b2a29d99a1657140f4e254221d8666a736160ce960d06557778318e0d1b7423b
